Productdetails:
|
| Spanning: | 380V/50Hz | Stroom: | 15 kW |
|---|---|---|---|
| gewicht: | 1600KG | Afmetingen: | 1800*1200*1750 |
| Materiaal: | SUS304/SUS316 | Capaciteit: | 5000-10000L/u |
| Functie: | Scheiding | Verwerking: | Verduidelijkend |
| kerncomponenten: | PLC, lager, motor | Inlaatdruk: | 0,05 MPa |
| Uitlaatdruk: | 0,1-0,4 MPa | Motorvermogen: | 15 kW |
| Roterende snelheid: | Hoog | Geluidsniveau: | Lager |
| Afdichtingstype: | Volledig verzegeld | ||
| Markeren: | industrial milk cream separator,disc oil separator machine,milk cream separator with warranty |
||
| Model | Treatment Capacity (L/H) | Inlet Pressure (Mpa) | Outlet Pressure (Mpa) | Motor Power (Kw) | Weight (Kg) | Outline Dimension (mm) |
|---|---|---|---|---|---|---|
| DHN360 | 2000-5000 | 0.05 | 0.1-0.35 | 7.5 | 1200 | 1530*1150*1500 |
| DHN470 | 5000-10000 | 0.05 | 0.1-0.4 | 15 | 1600 | 1800*1200*1750 |
| DHN550 | 10000-20000 | 0.05 | 0.1-0.4 | 22 | 2300 | 1950*1550*1960 |
| DHN616 | 25000-35000 | 0.1 | 0.3 | 37 | 3000 | 2185*1728*2082 |
